XIAO krmilnik razvojna plošča
Take a look at Seeeduino XIAO(Pre-Soldered). What a small size and cute looking! It is the smallest member of the Seeeduino family. Seeeduino XIAO(Pre-Soldered) still carries the powerful CPU-ARM® Cortex®-M0+(SAMD21G18) which is a low-power Arduino microcontroller. On the other hand, this little board has good performance in processing but needs less power. As a matter of fact, it is designed in a tiny size and can be used for Arduino wearable devices and small projects.
Powerful CPU: ARM® Cortex®-M0+ 32bit 48MHz
microcontroller(SAMD21G18) with 256KB Flash,32KB SRAM
Flexible compatibility: Compatible with Arduino IDE
Easy project operation: Breadboard-friendly
Small size: As small as a thumb(20×17.5mm) for wearable devices and small projects.
Multiple development interfaces:
11 digital/analog pins,
10 PWM Pins,
1 DAC output,
1 SWD Bonding pad interface,
1 I2C interface,
1 UART interface,
1 SPI interface.
Seeeduino XIAO(Pre-Soldered) is perfectly compatible with Arduino IDE, you can easily develop some small projects with the help of the large and comprehensive Arduino library.
CPU: ARM Cortex-M0+ CPU(SAMD21G18) running at up to 48MHz
Storage: 256KB Flash,32KB SRAM
I/O PINs: 14 GPIO PINs,11 analog PINs, 11 digital PINs, 1 DAC output Pin
Interface: 1 I2C interface,1 UART interface, 1 SPI interface
Power supply and downloading interface: USB Type-C interface
LEDs: 1 user LED, 1 power LED, two LEDs for serial port downloading
Reset button: two reset button short connect to reset
Power Pads: For the battery power supply
Software compatibility: Compatible with Arduino IDE
Projection cover for protecting the circuit
Dimensions: 20×17.5×6 mm
